Water-Activated Vinyl Paper Coating Machine

Send Inquiry

Request To Call Back

Water-Activated Vinyl Paper Coating Machine

Name: Foam Adhesive Tape Coating Machine
Brand: MOHINDRA MECHANICAL WORKS

Price 1500000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Water-Activated Vinyl Paper Coating Machine Specification

Max. Sheet Area
42 inches

Registration
Automatic Web Guiding

Machine Speed
150 m/m

Sheet Thickness
Approximately 40 300 GSM paper

Feeding Type
Continuous Web Feeding

Min. Sheet Area
12 inches

Coating Transfer Method
Direct or Reverse Roll Coating

Coating Format
Roll-to-Roll

Coating Type
Water-Based Adhesive / Vinyl Coating

Power Requirement
Three Phase

Product Type
Foam Adhesive Tape Coating Machine

General Use
Applying water-activated adhesive or vinyl-based coating on paper and flexible substrates

Material
Stainless Steel

Type
Other

Weight (kg)
8,000 Kilograms (kg)

Coating Speed
150 m/m

Coating Head
Gravure Roller

Coating Width
1600 Millimeter (mm)

Coating Material
Other

Computerized
No

Automatic
Yes

Control System
PLC Control

Power Source
Electric

Power Consumption
75-100 Kilowatt (kW)

Heating System
Hot Air

Drive Type
Electric

Voltage
380-440 Volt (v)

Humidification System
No

Glue Type
Water Based

Rewinder Type
Duplex Rewinder

Unwinder Type
Duplex Unwinder

Rewinding Width
600 1600 mm Millimeter (mm)

Unwinding Width
600 1600 mm Millimeter (mm)

Dimension (L*W*H)
14,000 3,800 4,500 Millimeter (mm)

Feature
Low Energy Consumption, High Speed, High Precision

Color
Green, White or Customized

Warranty
1 Year

Water-Activated Vinyl Paper Coating Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
2 Pieces Per Month

Delivery Time
60 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Export-worthy protective packing with waterproof wrapping; major assemblies securely fastened for transport

Main Export Market(s)
Africa, Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East

Main Domestic Market
Delhi

Certifications
Quality inspection certificate and electrical test report can be provided. CE-compliant configuration available on request.

Water-Activated Vinyl Paper Coating Machine About

The Water Activated Vinyl Paper Coating Machine manufactured by Mohindra Mechanical Works is designed for applying a smooth and uniform layer of water-activated adhesive or vinyl-based coating onto paper and compatible flexible web materials. The machine is suitable for manufacturing gummed paper, water-activated labels, packaging paper, sealing strips and other adhesive-coated products.

Its roll-to-roll configuration provides continuous material handling with controlled unwinding, precise coating application, multi-zone hot-air drying and uniform rewinding. The PLC-based control system allows operators to manage web speed, temperature, tension and coating parameters conveniently. Precision rollers and an automatic web-guiding arrangement help maintain coating consistency across the working width.

The machine can be supplied with gravure, Mayer bar or customized coating technology according to the required coating GSM and adhesive formulation. Its heavy-duty structure, stainless steel contact components and efficient drying system make it suitable for reliable industrial production.
