Waterproof Paper Coating Machine

Name: Aluminum Foil Paper Coating Machine
Brand: MOHINDRA MECHANICAL WORKS

Price 2000000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Waterproof Paper Coating Machine Specification

Power Requirement
Three-Phase Industrial Power Supply

Feeding Type
Roll Feeding

Coating Type
Single-Side Waterproof Barrier Coating

Varnish Type
Water-Based or Solvent-Based

Max. Sheet Area
42 Inches

Coating Transfer Method
Gravure/Mayer Bar Transfer

Max. Coating Area
Continuous Roll-to-Roll Coating

Min. Sheet Area
12 Inches

Registration
Automatic Web Alignment

Sheet Thickness
40 400 GSM

Machine Speed
150 m/m

Coating Format
Continuous Web Coating

Product Type
Automatic Waterproof Paper Coater

General Use
Waterproof and moisture-resistant paper coating

Material
Stainless Steel

Type
Other

Weight (kg)
6500 kg Approx. Kilograms (kg)

Coating Speed
150 m/m

Coating Head
Mayer Bar

Coating Width
600 1600 mm Millimeter (mm)

Coating Material
Other

Computerized
No

Automatic
Yes

Control System
PLC Control

Power Source
Electric

Power Consumption
Approximately 75 125 kW Kilowatt (kW)

Heating System
Hot Air

Drive Type
Electric

Voltage
380-440 Volt (v)

Humidification System
No

Glue Type
Water Based

Rewinder Type
Duplex Rewinder

Unwinder Type
Duplex Unwinder

Rewinding Width
Up to 1600 Millimeter (mm)

Unwinding Width
Up to 1600 Millimeter (mm)

Dimension (L*W*H)
10000 3200 3500 Millimeter (mm)

Feature
Low Energy Consumption, High Speed, High Precision

Color
White and Light Blue

Warranty
1 Year

Waterproof Paper Coating Machine Trade Information

Minimum Order Quantity
1 Piece

FOB Port
ICD Tughlakabad, New Delhi

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
2 Pieces Per Month

Delivery Time
60 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
The Waterproof Paper Coating Machine is securely packed using moisture-resistant wrapping, protective sheets, strong wooden supports and export-worthy packaging. The electrical panel, coating head, precision rollers and other sensitive components are separately protected during transportation.

Main Export Market(s)
Middle East, Asia, Western Europe, Australia, Central America, North America, South America, Eastern Europe, Africa

Main Domestic Market
Delhi

Certifications
Manufactured under an ISO-certified quality management system. Mechanical, electrical, heating and safety components are inspected before dispatch. Applicable documents can be supplied according to the final machine configuration and order requirements.

Waterproof Paper Coating Machine About

The Automatic Waterproof Paper Coating Machine manufactured by Mohindra Mechanical Works is designed for applying a smooth and controlled moisture-resistant barrier layer on paper, kraft paper and paperboard. It is suitable for manufacturing coated paper used in packaging, wrapping and various industrial applications where improved resistance to water, moisture, oil or grease is required.

The machine includes automatic unwinding, web guiding, closed-loop tension control, precision coating, multi-zone hot-air drying and controlled rewinding systems. Its PLC and HMI touchscreen allows operators to regulate machine speed, drying temperature, web tension and coating thickness conveniently. Precision rollers help maintain uniform coating across the entire paper width. The working width, coating head, drying length and heating system can be customized according to the paper GSM and selected barrier formulation.
