Kraft Paper Liner Coating Machine

Name: Kraft Paper Liner Coating Machine
Brand: MOHINDRA MECHANICAL WORKS
Price: 2000000.0 INR
Availability: InStock

Price 2000000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Unit

Kraft Paper Liner Coating Machine Specification

Max. Coating Area
Full Web Width

Coating Type
Kraft Liner Surface and Barrier Coating

Min. Sheet Area
As per Customer Requirement

Registration
Automatic Web Alignment

Sheet Thickness
80 400 GSM

Varnish Type
Water-Based Coating

Max. Sheet Area
32 Inches

Machine Speed
Up to 150 m/m

Feeding Type
Continuous Roll Feeding

Coating Format
Roll-to-Roll

Power Requirement
120 200 kW

Coating Transfer Method
Mayer Bar Coating

Product Type
Kraft Paper Liner Coating Machine

General Use
Applying Functional Coating on Kraft Liner Paper

Material
Stainless Steel

Type
Industrial Coating Machine

Weight (kg)
12000 Kilograms (kg)

Coating Speed
150 m/m

Coating Head
Mayer Bar

Coating Width
1600 Millimeter (mm)

Coating Material
Other

Computerized
Yes

Automatic
Yes

Control System
PLC Control

Power Source
Electric

Power Consumption
120 200 Kilowatt (kW)

Heating System
Hot Air

Drive Type
Pneumatic

Voltage
440v Volt (v)

Humidification System
No

Glue Type
Water Based

Rewinder Type
Duplex Rewinder

Unwinder Type
Duplex Unwinder

Rewinding Width
Up to 1600 Millimeter (mm)

Unwinding Width
Up to 1600 Millimeter (mm)

Dimension (L*W*H)
1800 450 500 Centimeter (cm)

Feature
High Precision, Low Energy Consumption, High Speed, Coating

Color
Green, White or Customized

Warranty
1 year

Kraft Paper Liner Coating Machine Trade Information

Minimum Order Quantity
1 Unit

FOB Port
ICD Tughlakabad, Delhi

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
2 Units Per Month

Delivery Time
90 Days

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
The machine is covered with waterproof protective wrapping. Electrical panels, coating assemblies, rollers, motors and sensitive components are properly protected. Major sections are securely fastened on wooden or steel supports to ensure safe transportation by road or sea. Export-worthy packaging can be provided according to customer requirements.

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
Delhi

Certifications
ISO 9001:2015 Certified, CE Certified Standard Machinery

Kraft Paper Liner Coating Machine About

The Kraft Paper Liner Coating Machine manufactured by Mohindra Mechanical Works is designed for applying functional and surface-enhancing coatings onto kraft liner paper and paperboard rolls. Depending on the selected formulation, the coating can improve surface smoothness, printability, bonding strength, moisture resistance, grease resistance and overall appearance.

The machine operates through a continuous roll-to-roll process comprising automatic unwinding, precise coating application, multi-zone hot-air drying and controlled rewinding. Its Mayer Bar coating arrangement provides consistent coat-weight control across the paper web. The PLC control system allows convenient adjustment of machine speed, web tension, coating parameters and drying temperature.

Automatic web guiding maintains proper material alignment, while the controlled drying chamber provides uniform moisture removal. Working width, coating head, drying length, heating source and production speed can be customized according to the kraft-paper grade and required finished properties.
